FEP Tubing Characteristics
Temperature Resistance:
Chemical Inertness:
Electrical Insulation:
Biocompatibility and Safety:
Physical Properties:
FEP Tubing Applications
Semiconductor and Electronics Industries:
It can be used to transport high-purity reagents and protect precision components, ensuring cleanliness during the manufacturing process due to its corrosion resistance and non-exfoliating properties.
It can also be used as insulation for wires in high-temperature, high-frequency environments (such as aerospace cables and computer internal connectors).
Medical:
Its excellent biocompatibility allows it to be used in drug delivery tubing, hemodialysis catheters, endoscope sheaths, and more. Food and
Pharmaceutical Industries:
It can provide sterile tubing that meets hygiene standards and prevents contamination.
Laboratory and Scientific Research Industries:
It can be used for chromatograph connectors, corrosive reagent transfer, and vacuum system piping.
Optical/Automotive and Aerospace Industries:
It can be used for high-temperature and wear-resistant component and wiring harness protection, laser equipment cooling tubes, and anti-stick roller liners.
FEP Tubing Main features and Application
| Usage | Wires, Cables, Sheaths, Electrical Components, Light Iron Pipes used at various frequencies and in places with relatively harsh working conditions, such as liquid level gauge tubes, various corrosive media (harsh solvents) delivery tubes, high-purity reagent delivery tubes, heat exchange tubes/steam pipes, single-ended luminous single-core optical fiber tubes, liquid crystal manufacturing equipment, fully covered fluorine plastic O-type high-resistance sealing ring tubes, high-profile wiring harness assembly tubes, semiconductor manufacturing equipment |
| Main features | 1. High-Temperature Resistance – Withstands temperatures up to 200°C (392°F) for use in high-temperature environments.
2. Chemical Resistance – Resists corrosion from acids, bases, solvents, and oils. 3. Low-Friction, Smooth Interior Surface – Minimizes signal loss and fiber damage during installation. 4. Flexible and Durable – Maintains structural integrity under mechanical stress and bending. 5. Flame Retardant – Meets industry safety standards (UL, RoHS compliant). 6. UV and Weather Resistant – Durable outdoors and in harsh conditions. 7. Available in Clear or Custom Colors – Convenient for visual inspection of fiber condition. |
| Application | 1. Telecommunications – Protects fiber optic cables in data centers and telecom infrastructure
2. Industrial Automation – For high-heat machinery, robotic systems, and sensor cabling 3. Aerospace & Defense – Shields optical fibers in avionics, radar systems, and military communications 4. Medical Devices – Ensures secure signal transmission in medical lasers and imaging equipment 5. Oil & Gas – Withstands aggressive chemicals and extreme temperatures in drilling operations 6. Renewable Energy – Protects optical fibers in solar panel and wind turbine monitoring systems |
| Samples | Free samples but need to pay for the courier charges |
Standard Sizes of FEP Tubing
| IDXOD
(mm) |
Packing in meters |
| 2×4 | 100 |
| 3×4 | 100 |
| 3×5 | 100 |
| 4×6 | 100 |
| 6.35×4.57 | 100 |
| 6×8 | 100 |
| 6.35*9.53 | 100 |
| 8×10 | 100 |
| 10×12 | 100 |
| 9.35*12.7 | 100 |
Can be customized according to customer size requirements
FEP is the full name of perfluoroethylene propylene copolymer, also known as fluorinated ethylene propylene copolymer.
FEP tubingare resistant to chemical corrosion, various strong acids and alkalis; they are resistant to high and low temperatures, and can work stably in extreme temperature environments from -200°C to 260°C.
Moreover, it has excellent electrical insulation, low friction coefficient, non-stickiness, and a smooth surface. In the fields of aerospace, medical, electronics, and chemical industry, FEP tubes play a key role.
Contact us today to request a quote or discuss your custom requirements.
